MILSPH/12 (MILSIH/12) TCC 2 AWG Cable Milkab - Mil Stok
    MILSPH/12 (MILSIH/12) TCC 2 AWG Cable Milkab - Mil Stok

MILSPH/12 (MILSIH/12), TCC, 2 AWG, 1 Meter

$69.862
Tax included

MILSPH/12 (MILSIH/12), TCC, 2 AWG Cable

Color : Gray

Volume discounts

Meter Unit Price Total Price
50+ 49.486 $ 2474.300 $
Quantity
Add to wishlist
Out of Stock

The minimum purchase order quantity for the product is 10 Meter

  Security Policy

Your payments are secure with SSL encryption.

  Delivery Policy

Fast and reliable delivery

SPECIAL INSULATION HIGH FLEXIBLE CONDUCTOR

  • Insulation Temperature: 180°C
  • Conductor Type: TCC
  • Voltage: 600 V
  • Section Range: 26-0000 AWG
PART NO AWG SIZE WIRE STRANDING STRUCTURE (nxd mm) CROSS-SECTIONAL AREA (mm²) WIRE STRANDING DIAMETER (mm) OUTER DIAMETER (mm) MAX RESISTANCE (Ohm/Km) CABLE WEIGHT (Kg/Km)
MILSPH/12-26-X 26 26x0.079 0.127 0.47±0.05 2±0.05 134.10 4.76
MILSPH/12-24-X 24 42x0.079 0.226 0.76±0.062 2.4±0.1 83.06 5.83
MILSPH/12-22-X 22 42x0.102 0.343 0.95±0.062 2.7±0.1 51.06 8.19
MILSPH/12-20-X 20 42x0.127 0.532 0.95±0.062 2.7±0.1 34.10 11.10
MILSPH/12-18-X 18 16x0.127 0.823 1.70±0.08 2.9±0.13 21.40 15.60
MILSPH/12-16-X 16 7x24x0.102 1.229 2.10±0.14 3.6±0.15 13.30 29.00
MILSPH/12-14-X 14 7x24x0.127 2.127 2.7±0.19 4.8±0.15 8.360 46.00
MILSPH/12-12-X 12 7x37x0.127 3.279 2.60±0.09 5.0±0.15 5.410 66.00
MILSPH/12-10-X 10 7x59x0.127 5.229 3.10±0.14 6.2±0.2 3.290 96.00
MILSPH/12-8-X 8 7x95x0.127 8.420 4.25±0.19 7.2±0.33 2.070 125.00
MILSPH/12-6-X 6 7x150x0.127 13.294 5.35±0.24 8.1±0.35 1.270 166.00
MILSPH/12-4-X 4 7x34x0.273 21.094 7.65±0.38 10.7±0.38 0.870 272.00
MILSPH/12-2-X 2 7x54x0.273 33.502 9.65±0.42 13±0.4 0.540 425.00
MILSPH/12-0-X 0 7x7x86x0.127 53.355 12.15±0.46 15.6±0.46 0.330 670.00
MILSPH/12-00-X 00 7x7x108x0.127 67.409 14.98±0.49 17.7±0.55 0.250 841.00
MILSPH/12-000-X 000 7x7x135x0.127 84.750 17.14±0.55 21.35±0.55 0.190 1,032.00
MILSPH/12-0000-X 0000 7x7x155x0.127 105.468 17.14±0.55 21.35±0.55 0.19 1,252.04
MILSPH/12-2-8
