MILSPH/12 (MILSIH/12), TCC, 10 AWG, 1 Meter

$14.903
Tax included

MILSPH/12 (MILSIH/12), TCC, 10 AWG Cable

Color : Green

Volume discounts

Meter Unit Price Total Price
50 - 99 10.557 $ 527.850 $
100 - 249 8.694 $ 869.400 $
250+ 6.209 $ 1552.250 $
Quantity
Add to wishlist
Product available with different options
(0 Items)

The minimum purchase order quantity for the product is 10 Meter

  Security Policy

Your payments are secure with SSL encryption.

  Delivery Policy

Fast and reliable delivery

Product Specifications

  • Isolation Type: (MILSIH) +150°C / High Flexible
  • Conductor Type: Tin Coated Copper (TCC)
  • Operating Voltage: 600 V

AWG Standart (TCC/NCC/SCC) High Flexible (TCC) Ultra High Flexible (TCC) 300 V 600 V 1000 V
30 (Ø0,304mm)/ 7 x 0,102 (Ø0,30mm)/ 11 x 0,08 Ø1,06±0,05
28 (Ø0,380mm)/ 7 x 0,127 (Ø0,38mm)/ 16 x 0,08 Ø1,14±0,05
26 (Ø0,495mm)/19 x 0,102 (Ø0,49mm)/30 x 0,08 Ø1,25±0,05 Ø2,00±0,05 Ø2,80±0,05
24 (Ø0,622mm)/19 x 0,127 (Ø0,622mm)/42 x 0,079 (Ø0,62mm)/40 x 0,08 Ø1,40±0,10 Ø2,10±0,10 Ø2,90±0,10
22 (Ø0,786mm)/19 x 0,160 (Ø0,786mm)/42 x 0,102 (Ø0,78mm)/60 x 0,08 Ø1,55±0,10 Ø2,40±0,10 Ø3,05±0,15
20 (Ø0,989mm)/19 x 0,203 (Ø0,989mm)/42 x 0,127 (Ø0,98mm)/100 x 0,08 Ø1,75±0,10 Ø2,70±0,10 Ø3,40±0,15
18 (Ø1,24mm)/19 x 0,254 (Ø1,24mm)/7 x 24 x 0,079 (Ø1,24mm)/150 x 0,08 Ø2,00±0,10 Ø3,10±0,13 Ø3,60±0,15
16 (Ø1,40mm)/19 x 0,287 (Ø1,40mm)/7 x 15 x 0,127 (Ø1,40mm)/252 x 0,08 Ø2,30±0,15 Ø3,20±0,15 Ø3,80±0,15
14 (Ø1,75mm)/19 x 0,361 (Ø1,75mm)/7 x 24 x 0,127 (Ø1,75mm)/400 x 0,08 Ø3,10±0,15 Ø3,60±0,15 Ø4,30±0,15
12 (Ø2,21mm)/37 x 0,320 (Ø2,21mm)/7 x 37 x 0,127 (Ø2,20mm)/680 x 0,08 Ø3,80±0,15 Ø4,10±0,15 Ø4,60±0,15
10 (Ø2,80mm)/37 x 0,404 (Ø2,80mm)/7 x 59 x 0,127 (Ø2,80mm)/1050 x 0,08 Ø4,60±0,15 Ø5,60±0,25 Ø6,00±0,25
8 (Ø4,20mm)/19 x (7 x 0,288) (Ø4,20mm)/7 x 95 x 0,127 (Ø4,20mm)/1650 x 0,08 Ø6,00±0,20 Ø7,20±0,33 Ø7,60±0,30
6 (Ø5,27mm)/19 x (7 x 0,361) (Ø5,27mm)/7 x 150 x 0,127 (Ø5,30mm)/3000 x 0,08 Ø7,10±0,20 Ø8,10±0,35 Ø8,40±0,25
4 (Ø6,66mm)/19 x (7 x 0,455) (Ø6,66mm)/7 x 7 x 34 x 0,127 (Ø6,65mm)/5000 x 0,08 Ø8,80±0,25 Ø10,70±0,38 Ø11,30±0,40
2 (Ø8,39mm)/19 x (35 x 0,254) (Ø8,39mm)/7 x 7 x 54 x 0,127 (Ø8,40mm)/6700 x 0,08 Ø11,0±0,30 Ø12,9±0,42 Ø13,30±0,45
0 (Ø10,40mm)/19 x (55 x 0,254) (Ø10,40mm)/7 x 7 x 86 x 0,127 Ø13,9±0,30 Ø15,5±0,46 Ø16,00±0,50
00 (Ø11,65mm)/19 x (70 x 0,254) (Ø11,65mm)/7 x 7 x 108 x 0,127 Ø14,8±0,35 Ø17,7±0,55 Ø18,30±0,60
000 (Ø13,20mm)/37 x (45 x 0,254) Ø16,4±0,40
0000 (Ø14,90mm)/37 x (57 x 0,25) Ø18,8±0,40
MILSPH/12-10-5[10HF7X59GR/MK-0000-0425]
